Description

Keyboard: « waterfall » keyboard, in 61-key (C-C)Touch Curve: 4 curves + 1 FixedKeyboard Mode: Single, Split, DualTranspose: +/- 6 semitonesOctave: +/- 2 octaveTechnology: TMT (Tonewheel Modeling Technology)+ HDS (High definition sampling)Parts: 3 Fully independent (Upper, Lower, Pedals)Sound Sections: 4 independent layers (Organ, Sound1, Sound2, Pedals)Power Supply: AC100/240VTechnologyTMT (Tonewheel Modeling Technology)Polyphony91 (tone wheels)Harmonic PercussionOn/Off, Soft/Normal, Decay Fast/Slow, Harmonic 3rd/2ndVibrato/ChorusUpper and Lower On/Off, V1/V2/V3/C1/C2/C3 mode selector, 4 PresetsRotary SpeakerOn/Off, Fast Slow/Stop speed, Drive, 8 Presets + 1 Custom with user selection of model, mic setup, memphis style, stop position, drum and horn balance, rotor speeds, rise and fall time, direct level, output level and eq.Additional ControlsAudio routing, reverb send, octave shift, keyclick, crosstalk, hum level, preamp ao-28, key comp, swell modeOrgan ModelsB3 (1938), C3 (1955), B3 (1967), BC (1936), B3 (1956), A100 (1961), Baroque Pipe, Romantic Pipe, Symph Pipe, Farf Organ, Vx OrganSOUND 1/2 SECTIONSTechnologyHDS (High Definition Sampling)Polyphony240Additional ControlsAudio routing, reverb send, octave shift, f. cutoff, f. resonance, attack, decay, release, control1, control2, brilliance, detune, velocity sensSounds119 (Pianos, E.Pianos, Synths, Pads, Strings, Choirs, Brass, Guitars, Chromatic Percs, Bells, Keyboards and others)PEDALS SECTIONTechnology AdditionalTMT (Tonewheel Modeling Technology) + HDS (High definition sampling)ControlsAudio routing, reverb send, octave shift, pedals sustain, f. cutoff, layer/split mode, velocity mode, thud modeBass Models22 (T.Wheel Bass, Baroque Bass, Romantic Bass, Symph Bass, Farf Bass, Vx Bass, Organ Bass, Acoustic Bass, Finger Bass, Fretless Bass, Picked Bass, Slap Bass, Rhod Bass, Dark Pk Bass, Synth Bass1-2-3-4-5-6, Fat Bass, DX Bass)EXT. ZONE 1/2/3 SECTIONSMaster keyboard3 External Zones assignable to Upper, Lower and Pedals parts.Additional ControlsOn/Off, Volume, midi/usb port, midi channel, octave shift, program change, bank msb, bank lsbEFFECTSMulti Effects2 Insert (IFX1, IFX2) + 1 Master (MFX)Effect Types14 Effect Types (Tremolo, Vibrato, Chorus, Flanger, Phaser, Wah, Amp, Delay, Ring Mod, PEq3, PEq5, GEq5, Comp, Simple Rot)Effect Presets108 Effect PresetsReverb13 Reverb Types (Small Room, Large Room, Small Hall, Medium Hall, Large Hall, Stage1, Stage2, Medium Plate, Large Plate, Spring 1, Spring 2, Tape 1, Tape 2)Master Eq3 band (Low, Mid, High) with programmable parametersINTERFACEDrawbars20 (9 Upper + 9 Lower + 2 Pedals)ControlsModulation Wheel, Pitch WheelDisplay128 x 64 OLED displayData Memory396 Programs (99 Banks x 4 Programs)CONNECTIONSAudioMain L(Mono)/R outs, Aux1/2 outs, Pedals out, Analog in, HeadphonesRotary Speaker11-pin socketMIDIIn/Out, Soft-Thru, Pedalboard InUSBto Host (Audio/Midi), to Device (Pen drive, Battery Charger)PedalExp Pedal, Damp Pedal, Rotary Switch, Foot Controller, Foot Switch Weight10 kg – 22.05 LbsDimensionsHeight cm 92,3 – 42.87″Width cm 32,8 – 12.91″Depth cm 11,1 – 4.37″
